415 Backhoe Loader

Net Power - SAE J134970HP

Displacement220in³

EmissionsEngine meets U.S. EPA Tier 4 Final/EU Stage V emission standards.

Net Power Rating at 2,200 rpm - SAE J134970HP

Net Power Rating at 2,200 rpm - ISO 924969HP

Power Rating Conditions - No De-Rating Required Up To10000ft

Net Torque Rise - 1,400 rpm - SAE J1349308ft-lb

Ratings at 2,200 rpm - Gross Power ISO 1439674HP

Net Torque Rise - 1,400 rpm85%

Ratings at 2,200 rpm - Gross Power SAE J199575HP

Engine ModelC3.6 55 kW (74 hp) Electronic Turbo Intercooled

Net Peak Power Rating @ 2,200 rpm - ISO 924971HP

Dimensions - Bore3.86in

Net Peak Power Rating @ 2,200 rpm - SAE J134970HP

Dimensions - Stroke4.72in

Dig Depth - Standard14ft

Operating Weight - Maximum24251lb

Cab - ROPS/FOPS306lb

Air Conditioning99lb

Auto-Shift Transmission269lb

MP Bucket (0.96 m3/1.25 yd3) - With Fold-Over Forks2017lb

Operating Weight - Maximum - ROPS Capacity24251lb

Operating Weight - Estimated*16279lb

MP Bucket (0.96 m3/1.25 yd3) - Without Fold-Over Forks1642lb

Ride Control33lb

Note*Machine configuration: standard stick hoe, OROPS canopy, 4WD standard shift transmission, 0.96 m³ (1.25 yd³) GP (General Purpose) loader bucket, 610 mm (24 in) standard duty hoe bucket, front 340/80-18 and rear 500/70-24 tires, 240 kg (530 lb) counterwei

Loader QC540lb

Counterweights, base - Maximum1014lb

Counterweights, base - Stackable, one529lb

Counterweights, base256lb

All-Wheel DriveSTD

Extendible Stick (excludes ft. counterweight)613lb

Pump TypeVariable-flow, Axial Piston

TypeClosed Center

System Pressure - Loader3336psi

System Pressure - Backhoe3336psi

Pump Capacity at 2,200 rpm34.9gal/min

NoteTravel speeds of backhoe loader at full throttle, when equipped with 500/70-24 rear tires.

Power-Shift Transmission - Optional - Forward - 4th25mile/h

Power-Shift Transmission - Optional - Reverse - 3rd17mile/h

Power-Shift Transmission - Optional - Forward - 2nd5.8mile/h

Power-Shift Transmission - Optional - Forward - 3rd12mile/h

Power-Shift Transmission - Optional - Reverse - 2nd7.6mile/h

Power-Shift Transmission - Optional - Forward -1st3.7mile/h

Power-Shift Transmission - Optional - Reverse - 1st3.7mile/h

Power Shuttle Transmission - Standard - Forward - 3rd13mile/h

Power Shuttle Transmission - Standard - Forward - 1st3.4mile/h

Power Shuttle Transmission - Standard - Reverse - 4th23mile/h

Power Shuttle Transmission - Standard - Forward - 2nd5.7mile/h

Power Shuttle Transmission - Standard - Forward - 4th23mile/h

Power Shuttle Transmission - Standard - Reverse - 1st3.4mile/h

Power Shuttle Transmission - Standard - Reverse - 2nd5.7mile/h

Power Shuttle Transmission - Standard - Reverse - 3rd13mile/h

Front Axle, AWD - Static51808lb

Front Axle, AWD - Dynamic19841lb

Rear Axle - Static58422lb

Rear Axle - Dynamic22046lb

Turning Circle - (inner wheel not braked) - Outside Front Wheels26.92ft

Stroke4.2in

Bore2.6in

TypeFront Wheel Steering

Power SteeringHydrostatic

Rod Diameter1.6in

Turning Circle - (inner wheel not braked) - Outside Widest Loader Bucket35.25ft

Axle Oscillation11°

CylinderOne Double-Acting

Hydraulic System25.1gal (US)

Rear Axle - Planetaries0.4gal (US)

Cooling System with Air Conditioning4.8gal (US)

Rear Axle4.2gal (US)

Hydraulic Tank11.1gal (US)

Fuel Tank42.3gal (US)

Engine Oil - With Filter2.4gal (US)

Transmission - Power Shuttle - AWD4.8gal (US)

Front Axle (AWD) - Planetaries0.2gal (US)

Front Axle (AWD)2.9gal (US)

Transmission - Power Shift - AWD5gal (US)

Recyclability92%

Standard

Air cleaner

Alarm, back-up

Audible system fault alarm

Backhoe controls, mechanical two lever

Battery, maintenance-free, 850 CCA

Battery disconnect switch

Boom transport lock

Brace, lift cylinder

Brake, parking, mechanical

Brakes, hydraulically boosted, oil disc, dual pedals, interlocking

Bucket level indicator

Canopy, ROPS/FOPS

Coat restraint

Coolant/antifreeze, extended life

Dome light (cab only)

Diagnostic port for engine

Differential lock, loader joystick

Drink holders, two

Engine, Cat C3.6 (Direct Injection Turbocharged), meets Tier 4 Final/Stage V emission standards, diesel particulate filter

Engine enclosure, sound suppression, removable side panels

Face seals, O-ring

Fan, suction and guard

Fast reversing shuttle, all gears

Fenders, rear

Filters, spin-on: fuel, engine oil, transmission oil, water separator

Filters, bowl and cartridge: hydraulic fluid

Flashing hazards/signal lights

Floor mat

Four wheel drive

Four wheel drive shaft guard

Fuel tank, fully enclosed

Fully hinged front grill for cooling package cleaning access

Gauge cluster: coolant temperature, fuel level, torque converter temperature, battery voltage

Ground level fuel fill

Halogen Lights, working (2 front, 2 rear)

High ambient cooling package

Hood lock, inside cab

Hydraulic hose, XT^™

Hydraulic oil cooler

Hydraulic oil level sight gauge

Hydraulic valves, loader 2 function

Hydraulic valves, backhoe 4 function

Hydraulics, load sensing with variable displacement piston pump

Indicator lights: wait to start, water in fuel, engine warning, warning lamp, regeneration inhibited, low engine oil pressure; LCD warnings: machine locked, service due, air filter blocked, auto idle shutdown, high coolant temperature, high torque converter temperature, high exhaust temperature, engine oil life indicator

Instrument panel lights

Key start/stop system

LCD operator display with soft key controls: engine speed, hour meter, gear/direction, battery voltage, hydraulic oil temperature, torque converter temperature, coolant temperature, trip totals (fuel and hours), lifetime totals (fuel and hours), operator settings (units, brightness, programmable hoe auxiliary flow), service mode diagnostics, oil life reset, DPF force regeneration, maintenance intervals, ECM/system info

Loader, self-leveling, return-to-dig and transmission disconnect switch

Loader, single tilt

Mirror, interior, rearview

Open circuit breather

Power receptacle, 5 volt USB, 1 internal

Power receptacle, 12 volt, 2 internal, 1 external

Power steering, hydrostatic

Product Link^™, cellular, network manager

Product Link, satellite, network manager

Seat belt, retractable, 51 mm (2 in)

Stabilizer shoes, street

Steering column, fixed

Steering knob

Seat, air suspension, vinyl cover, with armrest

Socket, two roof

Starting system, glow plugs

Steering, hydrostatic

Storage compartment, lockable

Storage tray

Stop and tail lights

Swing transport lock

Tires

Toolbox, external, lockable

Torque converter

Throttle, hand and foot, electronic

Transmission, four speed, manual, syncromesh

Transmission neutralizer switch

Transport tie-downs

Vandalism locks, three

Warning horn, electric

Optional

Auxiliary Hydraulics, rear, Adjustable Flow

Battery, additional, 850 CCA

Cab, standard

Cold weather fuel (–30° C/–22° F)

Cold weather package, including additional battery, engine block heater, radiator antifreeze (–50° C/–58° F), cold weather fuel (–30° C/–22° F) and mounting for an ether bottle

Counterweights, 115 kg (255 lb), 240 kg (530 lb) or 460 kg (1,015 lb)

Fenders, front with integral steps

Guard, boom protection plate

Guard, stabilizer, rock

Hydraulic valves, loader (3rd valve for MP or Quick Coupler)

Hydraulic valves, backhoe (5th and 6th function)

Hydraulic lines, combined function auxiliary

Joystick controls: pilot operated, excavator style with pattern changer

LED lights, working (2 front, 2 rear)

Pattern changer, in cab

Quick Coupler, hydraulic, dual lock

Quick Coupler, manual, dual lock

Quick Coupler, manual, pin lock

Radio and CD player, Bluetooth^®

Ride Control

Rotating beacon, magnetic mount

Seat, air suspension, fabric with armrest

Seat belt, retractable, 75 mm (3 in)

Security system, Bluetooth

Security System, operator display

Side mirrors, cab, external

Single Tilt Loader Coupler, Integrated Tool Carrier (IT) Interface

Stabilizer pads, grouser type

Stabilizer pads, reversible

Steering column, tilting

Stick, extendible

Vandalism protection, gauge cover

Work Tool Attachments such as buckets, forks, material handling arms, augers, hammers, brooms, cold planers and vibratory plate compactors. See your Cat dealer for more information.
