836 Landfill Compactor

Gross Power (SAE J1995:2014)562HP

Net Power (SAE J1349:2011)496HP

Net Power (ISO 9249:2007)502HP

Engine ModelC18

EmissionsU.S. EPA Tier 4 Final, EU Stage V, Korea Stage V and Japan 2014

Rated Speed1900r/min

Torque Rise52

Bore5.71in

Stroke7.2in

Displacement1104.5in³

High Idle Speed2120r/min

Low Idle Speed750r/min

Maximum Altitude without Derating7500ft

Note*Net power advertised is the power available at the engine flywheel when the engine is equipped with a fan, air cleaner, clean emissions module and alternator.

Maximum Operating Weight (Tier 3/Stage IIIA equivalent)125622lb

Transmission TypePlanetary - Powershift - ECPC

Direct Drive - Forward 14.3mile/h

Direct Drive - Forward 27.8mile/h

Direct Drive - Reverse 14.6mile/h

Direct Drive - Reverse 28.2mile/h

Steering System - CircuitFlow Sharing Implement; Pilot, load sensing

Steering System - PumpPiston – Variable Displacement

Relief Valve Setting - Steering3495lb/in²

Total Steering Angle86

Steering Cycle Times - High Idle3.9s

Steering Cycle Times - Low Idle6.4s

Fuel Tank209gal (US)

Diesel Exhaust Fluid Tank*9gal (US)

Cooling Systems - Tier 4 Final/EU Stage V40gal (US)

Cooling System - Tier 3/Stage IIIA Equivalent37.2gal (US)

Engine Crankcase16gal (US)

Transmission21.9gal (US)

Differential - Final Drives - Front49gal (US)

Differential - Final Drives - Rear50gal (US)

Hydraulic System - Implement/Steering46.2gal (US)

Hydraulic Tank Only27.2gal (US)

FrontPlanetary – Fixed

RearPlanetary – Oscillating

Oscillation Angle±6°

Service BrakesMulti Disc Wet (Enclosed) 2 WHL

Parking BrakeSpring Applied, Hydraulic Released

Operator Sound Level (ISO 6396)72dB(A)

Machine Sound Level (ISO 6395)111dB(A)

Operator Sound Level (ISO 6396)72dB(A)

Machine Sound Level (ISO 6395)109dB(A)

Height to Top of Beacon15.2ft

Height to Top of Air Conditioning Condenser15.2ft

Height - Cab Roof14.1ft

Height - Top of Exhaust Pipe15.1ft

Height - Top of Hood11.3ft

Ground Clearance to Hitch2.1ft

Ground Clearance to Bottom of Bumper3.2ft

Centerline of Rear Axle to Rear Compactor Guard11.3ft

Hitch to Centerline of Front Axle7.5ft

Wheel Base14.9ft

Width over Front Striker Bars12.9ft

Width over Rear Striker Bars12.9ft

Width over Platform10.5ft

Width over Drums14ft

Capacity25.9yd³

Height7.3ft

Height of Cutting Edge7.3ft

Capacity29.3yd³

Height7.3ft

Capacity33.6yd³

Height7.4ft

Standard

Standard and optional equipment may vary. Consult your Cat dealer for details.

Optional

Standard and optional equipment may vary. Consult your Cat dealer for details.

Standard

Advanced Productivity Electronic Control Shifting (APECS)

Air to air aftercooler

Brakes, fully hydraulic, enclosed, wet multiple disc brakes

Cat Clean Emission Module, insulated (Tier 4 Final/Stage V/Korea Stage V and Japan 2014)

Electro hydraulic parking brake

Engine, Cat C18: – Tier 4 Final/Stage V/Korea Stage V and Japan 2014 – Tier 3/Stage IIIA equivalent

Fuel priming pump, electric

Fuel to air cooler

Ground level engine shutoff

Guard (3 piece) transmission

Heat shield, turbo and exhaust manifold

Hydraulically driven demand fan

Integrated braking

Radiator, Aluminum Modular Radiator (AMR)

Separated cooling system

Starting aid (ether) automatic

Throttle lock

Torque converter with lockup clutch (LUC)

Turbine precleaner, engine air intake

Transmission, planetary, with 2F/2R speed range control

Underhood ventilation system

Standard

Alarm, back-up

Alternator, 150 amp

Batteries, maintenance-free (4-1,000 CCA)

Converter, 10-15 amp, 24V to 12V

Lighting system, halogen (front and rear)

Lighting, access stairway

Starter, electric (heavy duty)

Starter lockout (ground level)

Starting receptacle for emergency start

Transmission lockout (ground level)

Standard

Air conditioner w/roof-mounted condenser

Cab, sound-suppressed and pressurized

Internal four-post rollover protective structure (ROPS/FOPS)

Radio ready for (entertainment) includes antenna, speakers and converter (12V, 10-15 amp) 12V power port for mobile phone or laptop connection

Camera, rear vision

Coat and hard hat hooks

Flip-up armrest

Heater and defroster

Horn, electric

Hydraulic controls (floor mounted)

Implement hydraulic lockout

Laminated glass

Light, (dome) cab

Lunchbox and beverage holders

Instrumentation, Gauges: – DEF fluid level (Tier 4 Final/Stage IV) – Hydraulic oil temperature – Speedometer/tachometer – Torque converter temperature

Instrumentation, Warning Indicators: – Action alert system, three category – Axle/brake oil temp, front – Brake oil pressure – Electrical system, low voltage – Engine failure malfunction alert and action lamp

Mirrors, rearview (externally mounted)

Parking brake status

Radio, CB (ready)

Seat, Cat Comfort, (cloth) air suspension

Seat belt, retractable, 76 mm (3") wide

STIC Control System with steering lock

Sun visor, front

Glass (window) - rubber mounted glass

Transmission gear (indicator)

Vital Information Management System (VIMS) with graphical information display: external data port, customizable operator profiles

Wet-arm wipers/washers (front and rear)

Intermittent wipers (front and rear)

Standard

Wheels, paddle, plus, combination, and diamond wheel configurations

Standard

Guards, axle (front and rear)

Guards, cab window

Guards, crankcase and power train, hydraulically powered

Guards, rear fan and grill

Standard

Bulldozer arrangement is included in the standard equipment. Bulldozer blades are optional.

Standard

Antifreeze, premixed 50% concentration of extended life coolant with freeze protection to –34° C (–29° F)

Standard

Auto Blade Positioner (ABP)

Demand fan/swing out (hydraulic reversible)

Doors, service access locking

Ecology drains for engine, radiator, hydraulic tank

Electronic clutch pressure control and remote mounted pressure taps

Emergency platform egress

Engine, crankcase, 500 hour interval with CJ-4 oil

Fuel tank, 793 L (210 gal)

Hitch, drawbar with pin

Hoses, Cat XT^™

Hydraulic oil cooler

Hydraulic, steering and brake filtration/screening system

Oil sampling valves

Product Link^™ - Cellular

Stairways, fixed-L/R (rear access)

Steering, load sensing

Vandalism protection caplocks

Venturi stack

Optional

Straight blade

U-blade

Semi U-blade

Optional

Paddle

Plus

Diamond
