302 CR Mini Hydraulic Excavator

More

Machine Information

Specifications

Engine
Net Power
21 HP
Weights
Operating Weight
4987 lb
Dimensions - Long Stick
Dig Depth
101.2 in
Engine
Engine Model
Blade
Height
8.9 in
Dimensions - Standard Stick
Dig Depth
93.3 in
Weight Increase from Minimum Configuration
Steel Tracks
132 lb
Certification - Cab and Canopy
Top Guard
Dimensions - Long Stick
Track Belt/Shoe Width
9.8 in
Tail Swing
29.5 in
Dimensions - Standard Stick
Maximum Dig Height
139.8 in
Dimensions - Long Stick
Maximum Dump Clearance
103.9 in
Dimensions - Standard Stick
Track Belt/Shoe Width
9.8 in
Hydraulic System
Pump Flow at 2,400 rpm
17.4 gal/min
Digging Force - Stick - Standard
2540.3 lbf
Dimensions - Standard Stick
Tail Swing
29.5 in
Dimensions - Long Stick
Vertical Wall
76.4 in
Weight Increase from Minimum Configuration
Long Stick
18 lb
Dimensions - Standard Stick
Boom Height - Shipping Position
42.1 in
Dimensions - Long Stick
Boom In Reach
65.4 in
Hydraulic System
Auxiliary Circuit - Primary - Flow
8.7 gal/min
Dimensions - Long Stick
O/A Shipping Height
90.6 in
Weights
Maximum Operating Weight with Cab**
4987 lb
Dimensions - Standard Stick
O/A Shipping Height
90.6 in
Swing System
Machine Swing Speed
9.8 r/min
Engine
Note (2)
Dimensions - Standard Stick
Overall Shipping Length*
153.5 in
Sound
Average Exterior Sound Pressure (ISO 6395:2008)
93 dB(A)
Dimensions - Long Stick
Maximum Blade Depth
11.6 in
Hydraulic System
Digging Force - Bucket
4406.3 lbf
Service Refill Capacities
Cooling System
1 gal (US)
Hydraulic Tank
4.8 gal (US)
Dimensions - Long Stick
Track Width - Retracted
42.9 in
Service Refill Capacities
Hydraulic System
6.9 gal (US)
Dimensions - Standard Stick
Maximum Blade Height
11.2 in
Dimensions - Long Stick
Stick Length
45.7 in
Boom Height - Shipping Position
40.2 in
Maximum Reach
168.1 in
Blade
Width*
42.9 in
Travel System
Travel Speed - High
2.7 mile/h
Engine
Bore
3 in
Weights
Minimum Operating Weight with Canopy*
4229 lb
Dimensions - Standard Stick
Maximum Reach
161.8 in
Dimensions - Long Stick
Swing Bearing - Height
17.4 in
Boom Swing - Right
50 °
Dimensions - Standard Stick
Track Width - Expanded
55.12 in
Dimensions - Long Stick
Track Width - Expanded
55.12 in
Boom Swing - Left
65 °
Service Refill Capacities
Engine Oil
1.2 gal (US)
Engine
Stroke
3.2 in
Emissions
Dimensions - Long Stick
Maximum Dig Height
142.5 in
Hydraulic System
Auxiliary Circuit - Secondary - Pressure
3553.4 psi
Operating Pressure - Travel
3553.4 psi
Dimensions - Standard Stick
Track Width - Retracted
42.9 in
Dimensions - Long Stick
O/A Undercarriage Length
72.8 in
Weights
Note (2)
Sound
Note
Travel System
Travel Speed - Low
1.8 mile/h
Dimensions - Standard Stick
Boom Swing - Right
50 °
O/A Undercarriage Length
72.8 in
Engine
Displacement
69 in³
Travel System
Maximum Traction Force - Low Speed
4496.2 lbf
Weights
Maximum Operating Weight with Canopy**
4588 lb
Blade
Note
Dimensions - Standard Stick
Maximum Reach - Ground Level
159.1 in
Hydraulic System
Operating Pressure - Equipment
3553.4 psi
Dimensions - Long Stick
Maximum Blade Height
11.2 in
Service Refill Capacities
Fuel Tank
6.9 gal (US)
Dimensions - Long Stick
Maximum Reach - Ground Level
165.7 in
Dimensions - Standard Stick
Swing Bearing - Height
17.4 in
Dimensions - Long Stick
Overall Shipping Length*
152.8 in
Dimensions - Standard Stick
Stick Length
37.8 in
Hydraulic System
Operating Pressure - Swing
2132.1 psi
Engine
Note (1)
Dimensions - Standard Stick
Boom Swing - Left
65 °
Boom In Reach
65.4 in
Hydraulic System
Digging Force - Stick - Long
2203.1 lbf
Engine
Note
Hydraulic System
Type
Weights
Minimum Operating Weight with Cab*
4535 lb
Dimensions - Standard Stick
Maximum Dump Clearance
100.8 in
Travel System
Maximum Traction Force - High Speed
2967.5 lbf
Dimensions - Standard Stick
Minimum Ground Clearance Below Undercarriage
5.9 in
Maximum Blade Depth
11.6 in
Dimensions - Long Stick
Minimum Ground Clearance Below Undercarriage
5.9 in
Travel System
Gradeability - Maximum
Certification - Cab and Canopy
Roll Over Protective Structure (ROPS)
Weights
Note (1)
Dimensions - Long Stick
Note
Travel System
Ground Pressure - Maximum Weight
3.9 psi
Dimensions - Standard Stick
Note
Hydraulic System
Auxiliary Circuit - Primary - Pressure
3553.4 psi
Sound
Operator Sound Pressure (ISO 6396:2008)
73 dB(A)
Hydraulic System
Auxiliary Circuit - Secondary - Flow
3.7 gal/min
Certification - Cab and Canopy
Tip Over Protective Structure (TOPS)
Travel System
Ground Pressure - Minimum Weight
3.4 psi
Dimensions - Standard Stick
Vertical Wall
72.8 in
Weight Increase from Minimum Configuration
Expandable Undercarriage
212 lb
Weights
Note (3)
Engine
Net Power - 2,400 rpm - ISO 9249, 80/1269/EEC
21 HP
Weights
EU: CE Plate Weight with Cab***
4718 lb
Engine
Gross Power - SAE J1995:2014
21.6 HP
Weights
EU: CE Plate Weight with Canopy***
4508 lb
Sustainability
Recyclability

Additional Parts

Standard Equipment
ENGINE
HYDRAULICS
OPERATOR ENVIRONMENT
UNDERCARRIAGE
BOOM, STICK AND LINKAGES
ELECTRICAL
Optional Equipment
OPERATOR ENVIRONMENT
UNDERCARRIAGE
BOOM, STICK AND LINKAGES
ELECTRICAL
GUARDING
OTHER
