Net Power - ISO 9249146HP
Net Power - ISO 9249 (DIN)148hp (metric)
Engine ModelCat C4.4
Engine Power - ISO 14396148HP
Engine Power - ISO 14396 (DIN)150hp (metric)
Bore4in
Stroke5in
Displacement269in³
Biodiesel CapabilityUp to B20¹
EmissionsMeets U.S. EPA Tier 4 Final, EU Stage V, and Japan 2014 emission standards
Note (1)Net power advertised is the power available at the flywheel when the engine is equipped with fan, air intake system, exhaust system, and alternator with engine speed at 2,000 rpm. Advertised power is tested per the specified standard in effect at the time
Note (2)¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels** up to: 20% biodiesel FAME (fatty acid methyl ester)* or 100% renewable diesel, HVO
Operating Weight48500lb
NoteLong undercarriage, Reach boom, R2.9 (9'6") stick, General Duty (GD) 1.0 m³ (1.31 yd³) bucket, 700 mm (28 in) triple grouser shoes and 4200 kg (9,300 lb) counterweight.
Maximum Digging Depth22ft
BoomReach 5.7 m (18.8)
StickReach 2.9 m (9'6")
BucketGD 1.0 m³ (1.31 yd³)
Maximum Reach at Ground Level32.3ft
Maximum Cutting Height31ft
Maximum Loading Height21.3ft
Minimum Loading Height7.1ft
Maximum Depth Cut for 2440 mm (8 ft) Level Bottom21.6ft
Maximum Vertical Wall Digging Depth18.7ft
Bucket Digging Force - ISO28935lbf
Stick Digging Force - ISO22281lbf
Main System - Maximum Flow442 l/min (117 gal/min)
Maximum Pressure - Equipment5075psi
Maximum Pressure - Travel4974psi
Maximum Pressure - Swing3625psi
Swing Speed11.6r/min
Maximum Swing Torque54900ft·lbf
Fuel Tank Capacity86.6gal (US)
Cooling System6.6gal (US)
Engine Oil4gal (US)
Swing Drive - Each3.2gal (US)
Final Drive - Each1.1gal (US)
Hydraulic System - Including Tank61.8gal (US)
Hydraulic Tank30.4gal (US)
DEF Tank10.3gal (US)
BoomReach 5.7 m (18'8")
StickReach 2.9 m (9'6")
BucketGD 1.0 m³ (1.31 yd³)
Shipping Height - Top of Cab9.7ft
Handrail Height9.8ft
Shipping Length31.3ft
Tail Swing Radius9.3ft
Counterweight Clearance3.4ft
Ground Clearance1.5ft
Track Length14.7ft
Length to Center of Rollers11.11ft
Track Gauge7.9ft
Transport Width10.4ft
Air ConditioningThe air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 0.85 kg (1.9 lb) of refrigerant which has a CO2 equivalent of 1.216 metric tonnes (1.340 tons).
Recyclability97%
