Net Power - ISO 9249300HP
Net Power - ISO 9249 (DIN)304hp (metric)
Engine ModelCat C7.1 TTA
Engine Power - ISO 14396302HP
Engine Power - ISO 14396 (DIN)306hp (metric)
Bore4in
Stroke5in
Displacement428in³
Biodiesel CapabilityUp to B20¹
EmissionsMeets U.S. EPA Tier 4 Final, EU Stage V, and Japan 2014 emission standards.
Note (1)Net power advertised is the power available at the flywheel when the engine is equipped with fan, air intake system, exhaust system, and alternator with engine speed at 2,000 rpm. Advertised power is tested per the specified standard in effect at the time
Note (2)¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels** up to: 20% biodiesel FAME (fatty acid methyl ester)* or 100% renewable diesel, HVO
Operating Weight81100lb
Maximum Digging Depth26.11ft
BoomReach 6.5 m (21'4")
StickReach 3.9 m (12'10")
BucketHD 2.00 m³ (2.61 yd³)
Maximum Reach at Ground Level38.7ft
Maximum Cutting Height35.3ft
Maximum Loading Height24.6ft
Minimum Loading Height6.2ft
Maximum Depth Cut for 2440 mm (8 ft) Level Bottom26.6ft
Maximum Vertical Wall Digging Depth21.4ft
Bucket Digging Force - ISO47190lbf
Stick Digging Force - ISO32480lbf
Main System - Maximum Flow148gal/min
Maximum Pressure - Equipment5076psi
Maximum Pressure - Equipment - Lift Mode5511psi
Maximum Pressure - Travel5076psi
Maximum Pressure - Swing4264psi
Swing Speed8.84r/min
Maximum Swing Torque105250ft·lbf
Fuel Tank Capacity158.5gal (US)
Cooling System10.2gal (US)
Engine Oil6.6gal (US)
Swing Drive - Each4.8gal (US)
Final Drive - Each2.1gal (US)
Hydraulic System - Including Tank98.5gal (US)
Hydraulic Tank42.5gal (US)
DEF Tank13.2gal (US)
BoomReach 6.5 m (21'4")
StickReach 3.9 m (12'10")
BucketHD 2.00 m³ (2.61 yd³)
Shipping Height - Top of Cab10.5ft
Handrail Height10.5ft
Shipping Length36.8ft
Tail Swing Radius11.7ft
Counterweight Clearance4.2ft
Ground Clearance1.8ft
Track Length16.6ft
Track Length to Center of Rollers13.3ft
Track Gauge9ft
Transport Width - 850 mm (33”) Shoes11.9ft
Transport Width10.5ft
Recyclability98%
Air ConditioningThe air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.00 kg of refrigerant, which has a CO2 equivalent of 1.430 metric tonnes.
