D4 Dozer

Engine ModelCat C4.4

Power - Net130HP

Net Power - ISO 9249130HP

Net Power - ISO 9249 (DIN)132mhp

EmissionsU.S. EPA Tier 4 Final/EU Stage V/Japan 2014/Korea Tier 5

Note (1)Net power available at the flywheel when the engine is equipped with fan, air cleaner, aftertreatment, and alternator with engine speed at 2100 rpm. Advertised power is tested per the specified standard in effect at the time of manufacture.

Note (2)Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels up to: 20% biodiesel FAME (fatty acid methyl ester) ** or 100% renewable diesel, HVO (

Note (3)Machine Build Number 16A

Operating Weight29259lb

Power TrainHydrostatic Transmission

Fuel Tank69gal (US)

DEF Tank5gal (US)

Operating Weight29259lb

Ground Pressure5.9psi

Width of Standard Shoe22in

BladeVPAT or VPAT Foldable*

Blade Capacity4.26yd³

Operating Weight30882lb

Ground Pressure4.5psi

Width of Standard Shoe30in

BladeVPAT or VPAT Foldable*

Blade Capacity4.98yd³

Note*VPAT foldable blades have the same capacity and width as the XL/LGP VPAT blades.

Air ConditioningThe air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.6 kg of refrigerant which has a CO2 equivalent of 2.288 metric tonnes.

Standard

Standard and optional equipment may vary. Consult your Cat dealer for details.

Optional

Standard and optional equipment may vary. Consult your Cat dealer for details.

Standard

Cat C4.4 diesel engine

Air cleaner with integrated pre-cleaner, dust ejector and under hood air intake

Air-to-air aftercooling

Aluminum bar plate cooling system

Auto engine speed control

Dual path, closed loop, hydrostatic transmission

Electric fuel pump

Engine idle shutdown

Hydraulically driven, variable speed fan

Hydrostatic, infinite variable speed transmission

Optional

Precleaner with turbine

Auto reversing fan

Standard

Standard ROPS/FOPS cab

Integrated air conditioning

Air-suspension cloth seat

Adjustable armrests

10-in (254 mm) touch screen display

Rear vision camera

Electronically programmable speed selector

Programmable/selectable Bi-Directional shifting

Electronic engine air cleaner service indicator

12 V power port

Entertainment Radio ready

Optional

Comfort cab package

Heavy duty cab package

Radio, AM/FM/AUX/USB Bluetooth

Standard

Cat Technology: Stable Blade, Traction Control, Slope Indicate

Product Link, Cellular

Remote Flash/Troubleshoot

Operator ID

Machine Security - Passcode

Compatibility with radios and base stations from Trimble, Topcon, and Leica

Capability to install 3D grade systems from Trimble, Topcon, and Leica

Optional

ARO with Assist: includes Slope Assist, Attachment Ready Option (ARO), Third Party Grade Control Ready, Standard technology features

Cat Grade with 3D: includes full-color 10-inch (254 mm) touchscreen grade display, Grade receivers and antennas, Grade Software Enabled Attachment (SEA), ARO with Assist features

AutoCarryTM (requires Grade with 3D package)

Product Link, Dual Cellular/Satellite

Machine Security - Bluetooth

Standard

Heavy Duty undercarriage

Lifetime lubricated track rollers (8 + 2 carrier rollers) and idlers

Tracks 40 sections -560mm (22 in) Moderate Service - Standard

Tracks 40 sections -760mm (30 in) Moderate Service - LGP

Optional

Cat Abrasion undercarriage

Moderate service or Extreme Service track shoes

Track guiding guards - full, center, front/rear

Standard

105 Amp brush-type alternator (24 volt)

Backup alarm

Diagnostic connector

Integrated halogen lights - 4 front, 2 rear

Optional

6 LED lights

8 LED lights - premium

Flashing beacon

Standard

Three valve-hydraulics

Load sensing hydraulics

Standard

Extended service intervals

Ecology drains (engine oil, engine coolant, hydraulic)

Optional

Fast fill ready

Bio hydraulic oil

Cold weather package (120V or 240V)

Engine coolant heater (240V)

Shovel mounting bracket

Fuel refilling pump

High speed oil change

Standard

VPAT blade

Manual blade pitch

Optional

Folding VPAT blade

Power blade pitch

VPAT blade

Standard

Front pull device

Optional

Ripper Ready package

Winch ready

Dual Ripper/Winch Ready package

Winch (dealer installed)

Ripper with curved or straight shanks

Drawbar

Rear counterweight

Protection packages - standard, front or heavy duty guarding

Rear screen
