Engine ModelCat C7.1
Power - Net170hp
Net Power - Rated - ISO 9249/SAE J1349170hp
Net Power (Rated) - ISO 9249 (DIN)172mhp
EmissionsU.S. EPA Tier 4 Final/EU Stage V/Japan 2014 (Tier 4 Final)/Korea Stage V
Note (1)Rated horsepower at 1770 rpm. Net power advertised is the power available at the engine flywheel when the engine is equipped with a fan, air cleaner, clean emissions module and alternator. Advertised power is tested per the specified standard in effect at
Note (2)Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels up to: 20% biodiesel FAME (fatty acid methyl ester) ** or 100% renewable diesel, HVO (
Note (3)Basic machine specs provided below. For complete specifications and dimensions by configuration, blade and track shoe offerings and more, please visit the product download section to view the full Technical Specifications document.
Note (4)Machine Build Number 17B
Operating Weight42263lb
PowertrainFully Automatic 3-Speed
Fuel Tank83.2gal (US)
DEF Tank4.2gal (US)
Operating Weight37875lb
Ground Pressure6.9psi
Width of Standard Shoe24in
BladeVPAT
Blade Capacity4.6yd³
Operating Weight42263lb
Ground Pressure4.7psi
Width of Standard Shoe33in
BladeLGP VPAT
Blade Capacity5.5yd³
Operating Weight39198lb
Ground Pressure6psi
Width of Standard Shoe24in
BladeVPAT
Blade Capacity4.6yd³
Operating Weight38228lb
Ground Pressure7psi
Width of Standard Shoe24in
BladeSemi-Universal (SU)
Blade Capacity5.6yd³
Recyclability97%
Air ConditioningThe air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.36 kg of refrigerant which has a CO2 equivalent of 1.946 metric tonnes.
Note (1)Configurations and features may vary by region. Please consult your Cat dealer for availability in your area.
