Net Power13HP
Engine ModelYanmar 31NV70
Rated Speed2100r/min
Maximum Engine Output18HP
Gross Power - ISO 1439618HP
Diesel Tank Volume2.64gal (US)
Displacement52in³
Flywheel Output ISO13HP
Battery12 V, 20 Amp
TypeWater cooled model 3-cylinder diesel engine
Make/TypeYanmar 31NV70
EmissionsMeets U.S. EPA Tier 4 Final/EU Stage V emission standards.
Operating Weight2061lb
Operating Weight - Without Safety Frame2061lb
Operating Weight - With Safety Frame2170lb
Dig Depth68in
Undercarriage Width - Extended2.83ft
Width2.4ft
Height - With ROPS Safety Frame Folded Down4.94ft
Maximum Dump Height6.68ft
Maximum Dozer Lift Height8in
Length - Undercarriage4ft
Maximum Vertical Dig Depth4.43ft
Minimum Front Linkage Swing Radius3.77ft
Boom Swing Angle - Left55°
Undercarriage Width - Retracted2.33ft
Boom Swing Angle - Right56°
Maximum Reach10.09ft
Maximum Reach - Ground Level9.92ft
Transport Length - Arm Lowered9ft
Track Width7in
Tail Swing Radius2.41ft
Maximum Dozer Dig Depth7in
Maximum Dig Height9.39ft
Height - With ROPS Safety Frame Unfolded7.47ft
Pumps2 gear pumps
Discharge Capacity11.4 + 11.4 L/min (3 + 3 gal/min)
Operating Pressure for the Work and Travel Hydraulics2466psi
Operating Pressure Pivot1015psi
Hydraulic Tank Capacity3.7gal (US)
Track Width7in
Ground Clearance5in
Ground Pressure3.5psi
Machine Swing Speed8r/min
Number of Rollers - Each Side2
Gradeability30°/58%
Travel Speed1.12mile/h
Stick Length - Standard34.8in
Machine Overhang12.5in
Height8in
Dig Depth7in
Width28in
Lift Height8in
Sound Power Level (LWA) (to 2000/14/EG)93dB(A)
Operating Weight - Without Safety Frame2061lb
Digging Force - Bucket2000lb
Digging Force - Stick1011lb
Operating Weight - With Safety Frame2170lb
