Net Power13HP
Engine ModelYanmar 3TNV70
EmissionsMeets U.S. EPA Tier 4 Final/EU Stage V emission standards.
Operating Weight2399lb
Dig Depth68in
Dumping Height - Maximum80in
Stick Force1012lbf
Reach at Ground Level119in
Bucket Force2000lbf
Engine TypeLiquid Cooled, 3 Cylinder, Diesel
Gross Power13HP
Fuel Tank Capacity2.6gal (US)
Length × Width × Height2476 × 700 × 1507 mm (108 × 28 × 59 in)
Operating Weight2399lb
Shipping Weight2178lb
Pump TypeGear
Operating Pressure - Swing Gear1015psi
Operating Pressure - Front Linkage and Travel2466psi
Rotation Speed8r/min
Pump Flow6gal/min
Hydraulic Tank Capacity3.7gal (US)
Length × Width × Height930 × 720 × 1000 mm (36.5 × 28.3 × 39.5 in)
Operating Weight423lb
Hydraulic Oil Tank Capacity2.4gal (US)
Flow Rate5.3gal/min
Connecting Hose Length32.8ft
Operating Pressure2756psi
Input Current16A
Motor Type3 Phase Electric Motor
Performance - North America12HP
Performance - Europe10HP
Lift Height8in
Dig Depth7in
Width28in
Height8in
Travel Speed1.1mile/h
Track Width7.1in
