Net Power21HP
Engine ModelC1.1
Displacement69in³
Stroke3.2in
Bore3in
EmissionsMeets U.S. EPA Tier 4 Final and EU Stage V emission standards.
Net Power - 2,400 rpm - ISO 9249, 80/1269/EEC21HP
Gross Power - SAE J1995:201421.6HP
NoteNet power is tested per ISO 9249:2007 and 80/1269/EEC.
Note (2)Net power advertised is the power available at the flywheel when the engine is at rated speed and rated power when the engine is installed with the factory configured fan, air intake system, exhaust system, and alternator with a minimum alternator load.
Note (1)Engine power is tested per ISO 14396:2002.
Operating Weight3913lb
Minimum Operating Weight with Canopy*3483lb
Maximum Operating Weight with Canopy**3913lb
EU: CE Plate Weight***3836lb
Note (1)*Minimum Weight is based on rubber tracks, operator, fixed undercarriage and full fuel tank.
Note (2)**Maximum Weight is based on steel tracks, operator, expandable undercarriage and full fuel tank.
Note (3)***CE Plate Weight is based on the most common EU configuration. Includes 75 kg (165 lb) operator and full fuel tank and excludes bucket.
Dig Depth100in
Maximum Blade Height10.8in
Track Width - Expanded51.18in
Maximum Blade Depth10.2in
Maximum Reach - Ground Level153.1in
Stick Length45.7in
Swing Bearing - Height17.5in
Track Belt/Shoe Width9.1in
Boom Height - Shipping Position40.9in
Boom Swing - Right50°
Maximum Reach155.9in
Maximum Dig Height137.4in
Note*Overall Shipping Length depends on blade position during shipment.
Tail Swing32.3in
O/A Undercarriage Length57.5in
Boom In Reach57.1in
O/A Shipping Height90.9in
Overall Shipping Length*141.3in
Maximum Dump Clearance98.8in
Minimum Ground Clearance Below Undercarriage6.1in
Boom Swing - Left65°
Vertical Wall74.4in
Track Width - Retracted39in
Height8.9in
Note*Expanded – 1300 mm (51 in)
Width*39in
Swing Bearing - Height17.5in
Boom Swing - Left65°
Minimum Ground Clearance Below Undercarriage6.1in
O/A Undercarriage Length57.5in
Maximum Reach - Ground Level146.9in
Stick Length37.8in
Boom In Reach57.5in
Maximum Dump Clearance96.5in
Boom Swing - Right50°
Maximum Reach149.6in
O/A Shipping Height90.9in
Boom Height - Shipping Position42.9in
Maximum Blade Depth10.2in
Track Width - Retracted39in
Vertical Wall70.9in
Dig Depth92.1in
Track Width - Expanded51.18in
Track Belt/Shoe Width9.1in
Maximum Dig Height135in
Overall Shipping Length*142.5in
Maximum Blade Height10.8in
Note*Overall Shipping Length depends on blade position during shipment.
Tail Swing32.3in
Ground Pressure - Minimum Weight4psi
Maximum Traction Force - High Speed2315.5lbf
Ground Pressure - Maximum Weight4.4psi
Travel Speed - High2.7mile/h
Travel Speed - Low1.8mile/h
Maximum Traction Force - Low Speed3597lbf
Gradeability - Maximum30 degrees
Pump Flow at 2,400 rpm17.4gal/min
Digging Force - Stick - Standard1843.4lbf
Digging Force - Stick - Long1616.4lbf
Operating Pressure - Swing1493.9psi
Auxiliary Circuit - Secondary - Flow3.7gal/min
Auxiliary Circuit - Primary - Pressure3089.3psi
Auxiliary Circuit - Primary - Flow8.7gal/min
Auxiliary Circuit - Secondary - Pressure3089.3psi
Operating Pressure - Travel3089.3psi
Operating Pressure - Equipment3089.3psi
Digging Force - Bucket3169.8lbf
TypeLoad Sensing Hydraulics with Variable Displacement Piston Pump
Roll Over Protective Structure (ROPS)ISO 12117-2:2008
Tip Over Protective Structure (TOPS)ISO 12117:1997
Top GuardISO 10262:1998 (Level I)
Average Exterior Sound Pressure (ISO 6395:2008)93dB(A)
NoteEuropean Union Directive “2000/14/EC”
Steel Tracks126lb
Expandable Undercarriage284lb
Long Stick18lb
Cooling System1gal (US)
Engine Oil1.2gal (US)
Hydraulic System6.9gal (US)
Hydraulic Tank4.8gal (US)
Fuel Tank5.8gal (US)
Machine Swing Speed9.8r/min
Recyclability95%
