CB15 Tandem Vibratory Roller

The CB15 asphalt compactor offers enhancements that simplify operation, provide versatility, and deliver excellent fuel economy. Rotary dials, oscillatory vibration, and 360 degree seating option make this compactor a perfect match for urban streets, rural roads, highways, interstates and other high-production applications.

Request a Quote
View Rental Options Apply for credit

Standard - Operating Weight28958lb

Static Linear Load186lb/in

Maximum Operating Weight30391lb

Standard Compaction Width84in

Drum Offset6in

Curb Clearance28in

Ground Clearance11.5in

Engine ModelCat_C4.4

Gross Power142hp

High8mile/h

Low4mile/h

Overall Length15.5ft

Wheel Base11.25ft

Height - With ROPS/FOPS10ft

Overall Width92in

Centrifugal Force per Drum - Maximum31069lb

Centrifugal Force per Drum - Minimum12409lb

Maximum Amplitude0.041in

Minimum Amplitude0.01in

Maximum Frequency2520VPM

Minimum Frequency2520VPM

Vibration SelectionIndependent per drum, front only, rear only, both

Fuel Tank Capacity66gal (US)

Water Spray Tank Capacity264gal (US)

Standard

180 degree seat positioning with sliding station

Adjustable armrests

Platform ROPS/FOPS

Propel lever with 4-button control

Steering wheel - fixed position, left side

Suspension seat - no heat

76 mm (3 in) high visibility seatbelt

Vandalism protection

Optional

360 degree seat positioning with sliding station

Steering wheel - elevated position, left side

Suspension seat w/ heat

Seat headrest

Standard

Product Link™ PLE743

Remote Flash

Remote Troubleshooting

Optional

Infrared asphalt temperature sensors

CMV accelerometer - front drum

GNSS Mapping - temperature and passcount

Machine to machine communication

Product Link PLE783

Standard

Cat C4.4, 4-cylinder

Optional

Offset hitch

Standard

150 amp alternator

12-volt charging system

Automotive-type fuse system

Maintenance-free batteries

Cat Electronic Technician (Cat ET)

Remote start/charge receptacle

Standard

Maintenance-free Hitch

3 yr/3000 hr conventional vibratory system service interval

2 yr/2000 hr oscillatory vibration system service interval

Grouped filters with ground level access

Remote access drains

Sampling ports for Scheduled Oil Sampling

Site gauges

Standard

Backup Alarm

Warning horn (front & rear)

LED Working Lights

Steps, front drum fuel refill

Warning, LED safety beacons

Optional

LED Working Lights with turn signals

LED Roading Lights

Mirror package

Steps, rear drum water spray refill

Optional

Biodegradeable hydraulic oil

Five amplitude vibratory system

Two amplitude/two frequency vibratory system

Versa Vibe™ vibratory system

Two amplitude/two frequency w/Oscillation vibratory system

Versa Vibe w/Oscillation vibratory system

Cocoa mats

Mats - water distribution

Freeze protection - water spray system

Rear drum oscillation kit - field installed drum
