Rated Power - Peak335HP
Rated Power - Nominal295HP
Motor TypeSwitched Reluctance
Rated Torque (peak, nominal = @ 12 km/h [7.5 mph] and nominal power)3200 N·m/660 N·m (2360 lbf-ft/443 lbf-ft)
Efficiency95%
Cooling MethodLiquid
Ability of Regenerative BrakingYes
Service Interval12,000-13,000 hours
Bucket Capacities5.7-7.5 m³ (7.5-9.8 yd³)
Nominal Payload Capacity33069lb
Operating Mass107460lb
Shipping Weight114460lb
Breakout Force - Lift and Tilt53330lb
Static Tipping Load - Straight Ahead - Lift Arms Horizontal108500lb
Static Tipping Load - Full Turn - Lift Arms Horizontal89600lb
Ride ControlYes
Lift/Tilt System - CircuitElectro – Hydraulic, Positive Flow Control, Flow Sharing
Lift/Tilt System - PumpVariable Flow Piston/Hydraulic Load Sense
Maximum Flow78.5gal/min
Relief Valve Setting - Main4932psi
Lift Cylinder - Bore7in
Lift Cylinder - Stroke33in
Tilt Cylinder - Bore8in
Tilt Cylinder - Stroke22in
Raise6.8s
Dump3.3s
Lower, Empty, Float Down2.9s
Total Cycle Time13.2s
Rated Power (peak, nominal)303HP
Motor TypeSwitched Reluctance
Rated Torque (peak, nominal = 1,600 equivalent rpm)600 N·m/531 N·m (443 lbf-ft/392 lbf-ft)
Efficiency96%
Cooling MethodLiquid
Service Interval12,000-13,000 hours
Inverter Rating350A (nominal DC), 715VDC
Cooling MethodLiquid (coolant)
Component RatingsIP67, IP69K
Service Interval12,000-13,000 hours
0% Grade - Loaded11.2mile/h
0% Grade - Unloaded11.2mile/h
5% Grade - Loaded9.2mile/h
5% Grade - Unloaded11.2mile/h
10% Grade - Loaded5.3mile/h
10% Grade - Unloaded6.9mile/h
15% Grade - Loaded3.8mile/h
15% Grade - Unloaded4.9mile/h
20% Grade - Loaded3mile/h
20% Grade - Unloaded3.9mile/h
Battery ChemistryLi-lon
Battery MonitoringWith integrated Caterpillar controls systems
Pack Voltage - Nominal715 V
Pack Energy Capacity - Total213 kWh
Charging MethodUltra Fast Charge Onboard
On Board Fast Charging Charge time (0-100%)Less than 20 minutes (two MEC500 in parallel); Less than 30 minutes (one MEC500)
Battery Cooling MethodChilled Liquid (Extended Life Coolant)
Operating Temperature Limits (ambient)50° C/–20° C (122° F/-4° F)
Charging Current, Voltage1160A (output), 820VDC
Maximum Charging Rate840 kW (two MEC500 chargers)
Minimum Charging Rate500 kW
Charging RateUp to 4C (matched with MEC500 chargers)
