854 Wheel Dozer

Engine ModelCat C32B

Emissions (U.S. EPA Tier 4 Final): Net Power ISO - 9249814hp

Gross Power907hp

Emissions (U.S. EPA Tier 4 Final): Gross Power - SAE J1995900hp

Emissions (Tier 2 Equivalent): Gross Power - SAE J1995907hp

Emissions (Tier 2 Equivalent): Net Power ISO - 9249823hp

Rated Speed1750r/min

Bore5.7in

Stroke6.4in

Displacement1958in²

Peak Torque - 1,200 rpm3139lb/ft

Torque Rise30%

Note (1)Net power advertised is the power available at the flywheel when the engine is equipped with fan, air cleaner, muffler and alternator.

Note (2)Net torque rise meets SAE J139.

Note (3)No engine derating required up to 3050 m (10,000 ft) altitude.

Operating Weight224647lb

Transmission TypeCat Planetary Power Shift

Converter Drive - Forward 14.4mile/h

Converter Drive - Forward 27.7mile/h

Converter Drive - Forward 313.2mile/h

Converter Drive - Reverse 14.8mile/h

Converter Drive - Reverse 28.4mile/h

Converter Drive - Reverse 314.6mile/h

Direct Drive - Forward 1Lock-up disabled

Direct Drive - Forward 28.1mile/h

Direct Drive - Forward 314.2mile/h

Direct Drive - Reverse 15mile/h

Direct Drive - Reverse 28.9mile/h

Direct Drive - Reverse 315.6mile/h

NoteTravel speeds based on 45/65-45 L-5 46 ply tires.

Output at 1,850 rpm and 6900 kPa (1,000 psi)161gal/min

Cylinders, Double Acting - Lift, Bore and Stroke177 mm × 1760 mm (0.58 ft × 5.8 ft)

Cylinder, Double Acting - Tilt and Tip, Bore and Stroke267 mm × 286 mm (0.88 ft × 0.94 ft)

Fuel Tank - Standard413gal (US)

Cooling System53gal (US)

Crankcase32gal (US)

Transmission45gal (US)

Differential - Final Drives - Front98gal (US)

Differential - Final Drives - Rear90gal (US)

Hydraulic System - Steering and Engine Cooling Fan - Tank Only77gal (US)

Note (1)- All nonroad U.S. EPA Tier 4, European Union (EU) Stage IIIB and V, and Japan (MLIT) Step 4 diesel engines are required to use only Ultra Low Sulfer Diesel (ULSD) fuels containing 15 ppm (mg/kg) sulfer or less. Biodiesel blends up to B20 (20% blend by vo

FrontFixed

RearTrunnion

BrakesMeets ISO 3540:2011

Blade Capacities30.5 to 44.8 m3 (40 to 58.6 yd3)

Height - Top of ROPS18.25ft

Height - Top of Exhaust Pipe17.17ft

Height - Top of Hood13ft

Ground Clearance27in

Centerline of Front Axle to Hitch9.67ft

Centerline of Rear Axle to Edge of Bumper13.75ft

Wheel Base19.25ft

Length - With Blade on Ground44ft

Steering System - PumpPiston, variable displacement

Minimum Turning Radius - Over Blade31ft

Steering System - CircuitPilot, load sensing

Total Steering Angle86 degrees

Relief Valve Setting5004psi

Operating Weight224647lb

Sound Performance• The machine sound power level was measured according to ISO 6395:2008. The measurement was conducted at 70 percent of the maximum engine cooling fan speed. • The operator sound pressure level was measured according to ISO 6396:2008. The measurement was

Air ConditioningThe air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). See the label or instruction manual for identification of the gas. If equipped with 1234yf (Global Warming Potential =

ROPS/FOPSISO 3471:2008 and ISO 3449:2005 Level II Standards

Standard

Alternator, 150 amp

Batteries, maintenance free (4 – 1,400 CCA)

Battery disconnect and jump start receptacle, bumper

Deutsch terminal connectors

Electrical system, 24V

Electronic transmission control

Lighting system, halogen (front and rear) lighting, access stairway, engine compartment

Starter lockout in bumper

Starting and charging system, 24V

Transmission lockout in bumper

Optional

Lights, HID

Lights, LED

Product Link (Cellular)

Product Link (Satellite)

Standard

Brakes, oil cooled, multi-disc, service/secondary

Engine brake

Engine, Cat C32B

Fuel priming pump (electric)

Ground level engine shutoff

Axle oil coolers (front and rear)

Pre-cleaner, engine air intake (above hood)

Radiator, Aluminum Modular (AMR)

Starting aid, (ether) automatic

Throttle lock electronic

Torque converter, impeller clutch with lock-up clutch (ICTC) and rimpull control system

Transmission, 534 mm (21 in) planetary power shift (electronic) (3F/3R)

Optional

Driveline parking brake

No spin rear axle

Pre-cleaner, raised

Standard

Advisor display, displays real time operating information, performs calibrations and customizes operator setting

Air conditioner and heater with automatic temperature control

Air pre-cleaner, powered

Cab, sound-suppressed pressurized, separate external rollover protective structure (ROPS/FOPS)

Cigar lighter and ashtray

Coat hook

Converter (12V, 10-15 amp) and power port

Digital display on center console: gear, ground speed, machine hours

Electro-hydraulic blade controls, joystick

Heater and defroster

Horn, electric

Instrumentation, gauges: engine coolant temperature, fuel level, hydraulic oil temperature, powertrain oil temperature, tachometer

Instrumentation, warning indicators: action alert system – three categories, automatic transmission model enable status, brake malfunction, bucket float status, delayed engine shutdown status, engine idle shutdown status, engine malfunction, fuel economy mode enable status, hydraulic lockout, lockup clutch enable status, low fuel level, parking brake status, rimpull control enable status, seat belt warning, secondary steering (if equipped), throttle lock status, transmission gear

Light, cab, dome

Lunchbox and beverage holders

Premium seat with heated and actively cooled leather, adjustable lumbar support, air adjustable bolsters on the seat and backrest, seat cushion tilt adjustment, and adjustable-length seat cushion

Radio, AM/FM with Bluetooth^®, USB Port, 3.5 mm (0.14 in) auxiliary (AUX) input

Tinted glass

Wet-arm wipers/washers (front, rear, and corner) – intermittent front wiper

Optional

Radio, Sirius XM/AM/FM radio with Bluetooth technology, USB Port, 3.5 mm (0.14 in) AUX input

Rubber mounted cab glass

Window sun screen

Standard

Alarm, back-up

Camera, rear vision

Emergency platform egress

Implement lock out switch

LED warning strobe

Mirrors, rearview (externally mounted)

Seat belt, retractable, 76 mm (3 in) wide

Separate external protective structure (ROPS/FOPS)

Stairway, left and right rear access

Steering and transmission lock lever, cab

Steering, secondary

Seat, trainer with lap belt,

76 mm (3 in) wide

Toe kicks

Optional

Egress, powered rear access

Object detection (radar)

Wheel Chocks

Standard

Automatic Lubrication System greases the hitch, steering, and axle trunnion bearings

Axle ecology drains

Battery disconnect and jump start receptacle, bumper

Case drain filters

Coupling, Cat O-ring face seals

Engine, crankcase, 500 hour interval with CH4

Front walkway around cab

Guards, crankcase and power train

Ground-level fast fill fuel system

Ground-level service center with Electronic Technician (ET) port, fast fill fluid ports, ecology drains

Grouped/Labeled lube points

Hitch, drawbar with pin

Hoses, Cat XT^™

Oil sampling valves

Starter and Transmission lockouts in bumper

Sight gauges for steering, implement and transmission oil

Vital Information Management System (VIMS^™) 3G with graphical information display: external data port, customizable operator profiles

Optional

High pressure hydraulic oil screen

Product Link^™

Tire pressure monitoring

Standard

Standard ambient package (recommended for site conditions that do not exceed 43° C [110° F])

Optional

High ambient cooling system (recommended for ambient temperatures up to 50° C [122° F] for EPA Tier 4 Final emissions certified machines and 55 C [131 F] for EPA Tier 2 equivalent machines)

Standard

Heated Seat

Optional

Antifreeze, –50° C (–58° F)

120V or 240V coolant heating elements (recommended in conditions from –18° C to –30° C [0° F to –22° F])

Fuel heater (heated by recirculation using engine heat and a heat exchanger) (recommended in conditions from –18° C to –30° C [0° F to –22° F])

–40° C (–40° F) Hydraulic Oil, Arctic

Heater Mirrors

Standard

Economy mode with on-demand throttle

Positive Flow Control implement system

Impeller Clutch Torque Converter (ICTC) with lock-up clutch

Load-sensing steering

Soft detent controls

Engine idle management features: auto idle kickdown, delayed engine shutdown, engine idle shutdown

Standard

Front Fenders

Optional

Fender extensions, roading, front and rear

Optional

Semi-U, 30.5 m3 (40 yd3) HD Semi-U, 30.5 m3 (40 yd3) Coal, 44.8 m3 (58.6 yd3)

Paint, black blade rear

Optional

Cat Terrain ready

Optional

Tires 45/65R45

Tires 45/65-45

Rims only

Optional

Sound-suppression package
