XQ425

The Cat® XQ425 provides world class performance and enhanced usability. This model is powered by the fuel-efficient Cat C13 engine equipped with the Cat NOx Reduction System. Equipped with the new EMCP 4.4 control panel, the XQ425 features a user-friendly interface and automatic generator set paralleling. A principle advantage of the control system offers simpler and faster voltage changes. Providing greater flexibility when moving between multiple job sites with differing frequency and voltage needs, the auto-configuration capability eliminates the time required when reprogramming units and potential errors. Additional features include lower noise levels and improved part load fuel consumption.

Request a Quote

Rating Prime340 ekW (425 kVA)

Frequency50/60 Hz

Voltage120 - 600 V

Rating Standby375 ekW (469 kVA)

EngineC13

FuelDiesel

Height - Without Trailer60in

Length - Without Trailer208.7in

Width - Without Trailer104in

Weight with Lube Oil and Coolant, Without Trailer14700lb

100% Load 60Hz23.1gal/hr

75% Load 60Hz17.7gal/hr

50% Load 60Hz12.7gal/hr

100% Load 60Hz25.1gal/hr

75% Load 60Hz19.2gal/hr

50% Load 60Hz13.6gal/hr

Sound Power @ 7 meters (23 feet) @ All Ratings74 dB(A)

Standard

Heavy-duty.
Turbocharged.
After treatment

Standard

SR4B - 450 Frame

Standard

Digital EMCP4.2 set mounted controller

Standard

Provides package monitoring and management

Standard

Package mounted radiator with vertical air discharge.
Filled from factory

Standard

12V heavy duty starting motor and charging alternator c/w battery isolator

Standard

24 hour dual wall fuel tank with 3 way directional valve for external supply

Standard

Cyclonic/paper with dust cup and service indicator

Standard

Single, robust enclosure for controls and distribution c/w 4 pole circuit breaker and safety cut off

Standard

Heavy Duty steel base frame with integral fuel tank.
Lifting frame and 4 point lift.
base frame is wider than enclosure to protect generator set during transportation

Standard

Sound attenuating, galvanised steel enclosure with exceptional noise reduction performance

Standard

Integrated spark arresting silencer

Standard

On engine primary and secondary oil filters. Filled from factory

Standard

Factory tested and inspected
