Rating Prime310 kVA

Frequency50/60 Hz

Voltage127 - 480 V

Fuel/Emissions StrategyEU Stage V

EngineCat C9.3

FuelDiesel

Width60in

Height90in

Length161in

Weight - With Lube Oil and Coolant9046lb

100% Load 50 Hz17.7gal/hr

100% Load 60 Hz20.4gal/hr

75% Load 50 Hz13.2gal/hr

75% Load 60 Hz14.9gal/hr

Standard

Twin Turbocharged, air-to-air aftercooler

Electronic ECM controlled

Standard

Engine Mounted Clean Emissions Module (CEM)

Diesel Emissions Fluid (DEF)

Standard

LC5114N frame.

Coastal insulation protection

Standard

Digital EMCP4.2B set mounted digital controller.

Optional

ComAp InteliGen NTC, Deep Sea 7320, Deep Sea 8620, DEIF AGC-4

Syncronising capabilities

Standard

High Efficiency two stage air cleaner, with dust cup andservice indicator

Standard

Provides package monitoring and management.

Standard

Package mounted radiator with vertical air discharge. Filled from factory.

High ambient performance

Standard

24V heavy duty charging alternator with integral regulator

Standard

12hr dual wall fuel tank with internal fuel fill

Engine mounted primary and secondary fuel filter

Standard

Separate robust steel enclosures for control & distribution sections

4 pole, 630A main circuit breaker

Optional

CE socket box with integrated MCB & RCBO protection

Standard

Sound attenuating, galvanised steel enclosure with exceptional noise reduction performance.

Sealed quarter-turn compression latches with key orpadlock capabilities

Standard

On engine primary and secondary oil filters. Filled from factory.

Standard

Factory tested and inspected.

Full manufacturer's warranty,

Optional

Inboard mounted 3-way valve for external fuel connection, electronic fuel gauge and Bund Level Sender

Optional

Oil and coolant drains piped to baseframe
