Engine Power - ISO 14396174hp
Engine Power - ISO 14396 (DIN)176hp (metric)
Engine ModelCat C4.4
Net Power - ISO 9249171hp
Net Power - ISO 9249 (DIN)174hp (metric)
Bore4.1in
Stroke5.3in
Displacement268.5in³
Biodiesel CapabilityUp to B20¹
EmissionsMeets U.S. EPA Tier 4 Final and EU Stage V emission standards.
Note (1)Net power advertised is the power available at the flywheel when the engine is equipped with fan, air cleaner, Clean Emission Module (CEM) exhaust gas aftertreatment, alternator, and cooling fan running at intermediate speed. Rated speed at 2,200 rpm. Adv
Note (2)¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels** up to: 20% biodiesel FAME (fatty acid methyl ester)* or 100% renewable diesel, HVO
Operating Weight Maximum46740lb
Operating Weight Minimum41450lb
Note (1)Operating weight includes full fuel tank, operator, bucket 700 kg (1,543 lb) and dual pneumatic tires. Weight varies depending on configuration. Typical configurations include 2500 mm (8'2") stick, 3600 kg (7,937 lb) counterweight, bucket and 220 kg (485
Maximum Travel Speed21.7mile/h
Main System - Maximum Flow - Implement81gal/min
Maximum Pressure - Implement Circuit - Normal5076psi
Maximum Pressure - Implement Circuit - Heavy Lift5366psi
Maximum Pressure - Implement Circuit - Travel Circuit5076psi
Maximum Swing Speed*9.2r/min
Maximum Swing Torque38722lbf·ft
Note (1)*For CE-marked machine default value may be set lower
Fuel Tank124.2gal (US)
Diesel Exhaust Fluid (DEF)7.9gal (US)
Cooling System8.4gal (US)
Hydraulic Tank40.9gal (US)
Hydraulic System - Including Tank71.3gal (US)
BoomVariable Adjustable Boom 5260 mm (17'3")
Stick2500 mm (8'2")
BucketGD 0.98 m³ (1.28 yd³)
Shipping Height - Top of Cab11.1ft
Shipping Length29.3ft
Support Point11.7ft
Tail Swing Radius8.5ft
Counterweight Clearance4.3ft
Ground Clearance1.4ft
Undercarriage Length16.6ft
Wheel Base8.9ft
BoomVariable Adjustable Boom 5260 mm (17'3")
Stick2500 mm (8'2")
BucketGD 0.98 m³ (1.28 yd³)
Maximum Cutting Height32.6ft
Maximum Loading Height22.8ft
Maximum Digging Depth19.8ft
Maximum Vertical Wall Digging Depth13.9ft
Maximum Reach at Ground Line30.5ft
Stick Forces (ISO)20682lbf
Bucket Forces (ISO)30799lbf
Note (1)Range values are with dual pneumatic tires (10.00-20). Range values are calculated with a GD bucket (CW) and CW-30 quick coupler with a tip radius of 1535 mm (5'0"). Force values are calculated with heavy lift on, a GD bucket (pin-on) and a tip radius of
NoteThe air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 0.85 kg (1.9 lb) of refrigerant which has a CO2 equivalent of 1.216 metric tonnes (1.340 tons).
